Split AC - MSZ-HP 13VA
Climater offers top-tier Mitsubishi Split AC units, renowned for their superior cooling efficiency and innovative technology. Perfect for both residential and commercial spaces, these air conditioners provide consistent comfort with energy-saving features and whisper-quiet operation. Climater's expert team ensures seamless installation and maintenance, maximizing the lifespan and performance of your Mitsubishi Split AC. With a commitment to quality and customer satisfaction, Climater is your go-to solution for reliable and efficient air conditioning, delivering a perfect blend of comfort and sustainability.
Features
Auto Horizontal Vane
Auto Fan Speed Mode
Grooved Piping
DC Fan Motor
Econo Cool-Smart Save
Joint Lap DC Motor
Technical Specifications
| Type (Cooling) |
|---|
| Indoor Unit |
| MSZ-HP13VA |
| Outdoor Unit |
| MUZ-HP13VA |
| Performance Parameters | |
|---|---|
| Capacity (Tr) | 1 Tr |
| Star Rating - As Per BEE | 3 Star  |
| Power Supply | 230 V / 50 Hz / Single Phase |
| Cooling Capacity (Rated Min-Max) | 3.15(1.4-3.50)kW |
| Heating Capacity (Rated Min-Max) | 3.60(1.1-4.10)kW |
| Total Input (Rated Min-Max)-Cooling | 1.04(0.36-1.27)kW |
| Total Input (Rated Min-Max)-Heating | 0.995(0.37-1.2)kW |
| ISEER | 3.62 |
| Operating Current (Rated)-Cooling | 5.1(A) |
| Operating Current (Rated)-Heating | 4.7(A) |
| Air Volume (CFM) Indoor Unit(Low/Mid/High/SHi)-Cooling | 134/204/278/386 |
| Air Volume (CFM) Indoor Unit(Low/Mid/High/SHi)-Heating | 122/195/270/366 |
| Dimensions & Weight | |||
|---|---|---|---|
| Indoor unit | Dimensions (H x W x D) | mm | 290x799x232 |
| Weight | kg | 9 | |
| Outdoor unit | Dimensions (H x W x D) | mm | 538x699x249 |
| Weight | kg | 25.0 | |
| Breaker Size (MCB required) | A | 10 | |
| Ext.Piping | Diameter Liquid | mm (inches) | 6.35(1/4) |
| Diameter Gas | mm (inches) | 9.52(3/8) | |
| Max.Length Out-In | m | 20 | |
| Max.Height Out-In | m | 12 | |
| Compressor, Refrigerant & Ambient Operations | |||
|---|---|---|---|
| SPL Indoor Unit(Low/Mid/High/SHi) In dB(A)-Cooling | 22/31/38/45 | ||
| SPL Indoor Unit(Low/Mid/High/SHi) In dB(A)-Heating | 23/30/37/44 | ||
| Refrigerant | R410A  |
||
Book Your Product
