Ductable AC - DHAM Series
Climater offers top-notch solutions with Mitsubishi Ductable AC, ideal for maintaining consistent and efficient cooling across large spaces. These systems are known for their superior performance, energy efficiency, and quiet operation, making them perfect for commercial and residential applications. With Climater's expert installation and maintenance services, you can experience seamless climate control tailored to your needs. Trust Climater to provide reliable, advanced air conditioning solutions that enhance comfort and reduce energy costs, all backed by Mitsubishi's cutting-edge technology.
Features
100% Copper
Airfilter
Anti-rust
Auto Restart
Self Diagnostic Function
Timer
Technical Specifications
| Type (Cooling and Heating) |
|---|
| Indoor Unit |
| DHAM-102KVR-Y1-Q |
| Outdoor Unit |
| DHBM-102KPR-Y1-Q |
| Indoor Unit | |||
|---|---|---|---|
| Rated Power supply | 400+/-10%-3-50 | V-ph-Hz | |
| Cooling | Tonnage Category | 8.5 | Tr |
| Nominal Cooling Capacity | 29894 | W | |
| Input Power | 11800 | W | |
| Power Supply | 230+/-10%-1-50 | V- Ph-Hz | |
| Blower & Housing | Type of Blower | DIDW, Forward Curve | Type |
| Blower Material | Aluminium | Type | |
| Housing material | GI | Type | |
| No. of Blower | 2 | Nos. | |
| Indoor coil | Number of rows | 3 | Nos. |
| Fin type | Hydrophilic aluminium | Type | |
| Indoor Air Filter | Included | ||
| Indoor Air Flow | 3846 | CFM | |
| Indoor Static pressure | 30 | Pa | |
| Indoor unit | NET Dimension(WxDxH) | 1620x675x460 | mm |
| GROSS Packing (WxDxH) | 1765x680x465 | mm | |
| Net/Gross weight | 85/100 | Kg | |
| Drainage water pipe dia. | 0DΦ27.5mm | mm | |
| Refrigerant piping | Liquid side | 5/8” Flared Connections | Inch /Type |
| Gas Side | 9/8” Brazed Connection | Inch/Type | |
| Operation temperature | Cooling | 17~50 | |
| Remote Control | Wired Controller | Type | |
| Outdoor Unit | |||
|---|---|---|---|
| Number of Outdoor | 1 | No. | |
| Power supply | 400+/-10%-3-50 | V- Ph-Hz | |
| Compressor | Type | Scroll | |
| Outdoor coil | Number of rows | 2 | no. |
| Outdoor unit | Dimension (WxDxH) | 1650x620x940 | mm |
| Packing (WxDxH) | 1750x708x1070 | mm | |
| Refrigerant type/Quantity | Refrigerant | R410 | Type |
| Charged volume | 6600 / 7.5 mtr | gm / mtr | |
| Refrigerant piping | Liquid side | 5/8” Flared Connections | Inch/Type |
| Gas Side | 9/8” Brazed Connection | Inch/Type | |
| Max. pipe length | 35 | m | |
| Max. difference in level | 20 | m | |
